Modern double din radio
- Thread starter snes
- Start date
I've done a couple double-din installations on 1997 Marks now, and both were possible, but required some creativity for fit.
Basically, there was some plastic structure that needed to be cut out behind the dash to accommodate the "body" of the stereo, but the opening for the faceplace was actually slightly larger than standard double-din. This required me to make a custom "adapter" for the faceplate to achieve a clean finish. the first install was very thin plywood, my second was actually a scrap of Laminate flooring left over from a bathroom remodel. (then painted black..) Both worked well. and until now, nobody knew about the flooring.
One of those oscillating "wiggle tools" is useful for cutting. I used a rotozip on my first attempt and it was... messy.
My increasingly fuzzy memory is telling me that a '95 is a double-din also, (where 93-94 were not.) Others here will correct me if I'm off by a year. In which case none of what I've just typed will be helpful.
Basically, there was some plastic structure that needed to be cut out behind the dash to accommodate the "body" of the stereo, but the opening for the faceplace was actually slightly larger than standard double-din. This required me to make a custom "adapter" for the faceplate to achieve a clean finish. the first install was very thin plywood, my second was actually a scrap of Laminate flooring left over from a bathroom remodel. (then painted black..) Both worked well. and until now, nobody knew about the flooring.
One of those oscillating "wiggle tools" is useful for cutting. I used a rotozip on my first attempt and it was... messy.
My increasingly fuzzy memory is telling me that a '95 is a double-din also, (where 93-94 were not.) Others here will correct me if I'm off by a year. In which case none of what I've just typed will be helpful.
I'd wait for a "gen 1" pro to chime in, but based on what I've seen, I wouldn't guarantee it. The overall shape is very similar to the factory deck, so "maybe." It's all about how thick the face is.
What I can say is that the mounting kit is likely unnecessary, unless you're just jamming it in there as a wedge. I've always found better methods..
What I can say is that the mounting kit is likely unnecessary, unless you're just jamming it in there as a wedge. I've always found better methods..
